Woods Timer 50007: Comprehensive Instructions
Woods Wire’s 50007 Indoor Digital 24-Hour Slim Fit Timer offers automated control; it’s designed for simple operation and reliable performance.
This guide provides detailed instructions‚ covering setup‚ programming‚ troubleshooting‚ and safety precautions for your new timer.
Ensure you charge the internal battery initially‚ then plug the timer and your desired device into appropriate outlets for seamless operation.
Overview of the Woods Timer 50007
The Woods Timer 50007 is a versatile‚ indoor digital timer designed to automate the control of lights‚ fans‚ and other electrical devices. This slim-fit timer features a 24-hour operation cycle and a single polarized outlet‚ making it ideal for everyday household use.
It’s a cost-effective solution for energy management and enhanced home security‚ simulating occupancy while you’re away. The timer allows users to pre-set on and off times‚ eliminating the need for manual operation.
Available in convenient 2-packs‚ the Woods 50007 is easy to program and operate‚ offering a user-friendly experience. It’s a practical addition to any home‚ providing convenience and peace of mind. Remember to consult the full manual for detailed instructions.
Key Features and Specifications
The Woods Timer 50007 boasts several key features‚ including a 24-hour digital display for precise time setting and programming. It operates on a single polarized outlet‚ ensuring safe and reliable operation. The internal battery provides backup during power outages‚ preserving programmed settings.
Specifications include a maximum load capacity suitable for most household appliances. The timer’s slim design allows it to blend seamlessly into any environment. Programming is straightforward‚ with intuitive controls for setting multiple on/off cycles.
Its primary function is automated control‚ offering convenience and energy savings. The override function allows for manual operation when needed. Detailed instructions are available in the manual‚ ensuring easy setup and use.
Setting Up the Timer
Begin by charging the internal battery for ten minutes‚ then plug the Woods 50007 into a wall outlet with your device connected.
Initial Battery Charge
Prior to first use‚ it is crucial to adequately charge the internal rechargeable battery of your Woods 50007 timer. This ensures reliable operation and accurate timekeeping‚ even during power outages.
To initiate the charging process‚ simply plug the timer directly into a standard wall outlet – do not connect any device to the timer at this stage. Allow the timer to remain plugged in for a minimum of 10 minutes.
This initial charge provides sufficient power for the timer to function correctly. While the timer can operate while plugged in without a fully charged battery‚ a complete initial charge is highly recommended for optimal performance and longevity of the internal battery;
Plugging In the Timer and Device
Once the initial battery charge is complete‚ you can proceed to connect your desired appliance or device to the Woods 50007 timer. First‚ ensure the device is switched ON. This allows the timer to properly control its power supply.
Plug the appliance’s power cord firmly into the polarized outlet on the front of the timer. Then‚ plug the entire timer unit into a standard wall outlet. Verify that both connections are secure to prevent interruptions in power delivery.
The timer is now ready to operate according to your programmed settings. Remember to check that the device is functioning as expected after connecting it to the timer.
Understanding the Display Panel
The Woods 50007 features a clear‚ easy-to-read digital display panel. This panel provides essential information regarding the timer’s current status and programmed settings. Key elements include the current time display‚ showing hours and minutes.
You’ll also find indicators for programmed ON and OFF times‚ visually confirming the active schedule. A small LED typically illuminates when the timer is in the ON state‚ providing a quick visual cue. The ‘SET’ button indicator shows when you are in programming mode.
Familiarize yourself with these indicators to quickly assess the timer’s operation and make necessary adjustments. Understanding the display is crucial for effective programming and monitoring.
Setting the Current Time
To accurately program your Woods 50007‚ setting the correct current time is essential. Press and hold the ‘SET’ button‚ then use the ‘+’ or ‘-’ buttons for adjustments.
Entering Time Setting Mode
Initiating the time setting process on your Woods Timer 50007 is straightforward. Begin by pressing and holding the ‘SET’ button for approximately two seconds. You’ll notice the display will begin to flash‚ indicating that the timer has transitioned into time setting mode.
Typically‚ the hour digits will flash first‚ signaling that you are now ready to adjust the hour. If the display doesn’t immediately enter setting mode‚ repeat the process of pressing and holding the ‘SET’ button.
Ensure the timer is properly plugged in and has sufficient battery charge for accurate operation during this process. A stable power supply is crucial for retaining the set time. Once in setting mode‚ proceed to adjust the hour using the designated buttons.
Adjusting the Hour
With the hour digits flashing on the display‚ use the ‘▲’ or ‘▼’ buttons to increment or decrement the hour. Each press of these buttons will adjust the hour by one‚ allowing for precise setting of the current time.
Pay close attention to the AM/PM indicator‚ if present‚ to ensure you are setting the correct time of day. The timer operates on a 24-hour cycle‚ so be mindful of this when setting the hour.
Once the desired hour is displayed‚ press the ‘SET’ button again to confirm your selection and move on to adjusting the minutes. This confirms the hour setting and prepares the timer for minute adjustment.
Adjusting the Minutes
After confirming the hour‚ the minute digits will begin to flash on the display panel. Utilize the ‘▲’ or ‘▼’ buttons to increase or decrease the minute value. Each button press will adjust the minutes by one‚ enabling accurate time synchronization.
Carefully observe the display to ensure you are setting the correct minute. Take your time to avoid errors‚ as precise timing is crucial for the timer’s functionality. Double-check the displayed minutes before finalizing the setting.
Once the desired minute is shown‚ press the ‘SET’ button one final time. This action confirms the minute setting and completes the current time configuration process‚ returning the timer to its standard display mode.
Programming On/Off Times
To automate your devices‚ enter programming mode and define specific ‘ON’ and ‘OFF’ times. This allows for scheduled operation‚ enhancing convenience and energy savings.
Entering Programming Mode
To initiate programming on your Woods 50007 timer‚ begin by pressing and holding the “SET” button for approximately two seconds. The display will then begin to flash‚ indicating that the timer is now in time setting mode‚ which is the first step towards programming on/off schedules.
Once in this mode‚ you’ll be able to adjust the hour and minutes to reflect the current time‚ a crucial prerequisite for accurate scheduling. After setting the current time‚ subsequent presses of the “SET” button will cycle you through the various programming options‚ allowing you to define your desired on and off times.
Pay close attention to the display as you navigate these settings‚ ensuring that you are configuring the timer according to your specific needs. Remember to confirm each setting by pressing the “SET” button again.
Setting the On Time
After entering programming mode and navigating to the “On Time” setting – typically indicated by a flashing “ON” on the display – you’ll use the up (▲) or down (▼) buttons to adjust the hour for when you want your device to power on. Pressing these buttons will increment or decrement the hour‚ allowing for precise selection.
Once the desired hour is set‚ press the “SET” button again to move to the minutes setting. Repeat the process using the ▲ or ▼ buttons to adjust the minutes until the correct “On Time” is displayed.
Confirm your selection by pressing “SET” one final time; the display will stop flashing‚ indicating the “On Time” has been successfully programmed.
Setting the Off Time
Following the successful programming of the “On Time”‚ the timer will automatically transition to setting the “Off Time”. The display will likely show a flashing “OFF” indicator‚ signaling you’re in the correct mode. Utilize the ▲ (up) or ▼ (down) buttons to adjust the hour at which you want your connected device to switch off.
Pressing these buttons will cycle through the hours‚ allowing you to pinpoint the desired shut-off time. Once the correct hour is displayed‚ press the “SET” button again to move onto adjusting the minutes.
Again‚ use the ▲ and ▼ buttons to fine-tune the minutes until the precise “Off Time” is shown. Confirm your settings by pressing “SET” – the flashing will cease‚ confirming the “Off Time” is programmed.
Multiple On/Off Programs
The Woods Timer 50007 allows for the creation of multiple on/off cycles‚ providing flexibility for diverse scheduling needs. After setting your first on/off program‚ you can add additional cycles to automate various tasks throughout the day. To initiate programming for a new cycle‚ press the “SET” button again.
The timer will revert to the “On Time” setting mode‚ allowing you to define another activation period. Repeat the process of setting the “On Time” and “Off Time” as previously described. The timer can accommodate several distinct on/off programs‚ enabling complex automation.
Each program will execute sequentially‚ offering a comprehensive scheduling solution. Remember to review all programmed cycles to ensure they align with your intended usage.
Override Functionality
To manually override the timer‚ press the ON button to activate the device immediately; press again to return to the programmed schedule.
Manual Override Operation
The Woods 50007 timer offers a convenient manual override function‚ allowing you to instantly control the connected device‚ bypassing the programmed schedule. To activate this feature‚ simply press the “ON” button located on the timer’s face. Upon pressing‚ the device plugged into the timer will immediately power on‚ regardless of its scheduled on/off times.
This is particularly useful for situations where you need temporary access to the device outside of its regular operating hours. The timer will remain in the “ON” state until you manually deactivate the override. To return to the programmed schedule‚ press the “ON” button again. This will revert the timer to its pre-set timings‚ ensuring automated operation resumes as intended. Remember‚ the override function doesn’t erase your programmed settings; it merely temporarily suspends them.
Returning to Timed Operation
After utilizing the manual override function on your Woods 50007 timer‚ seamlessly returning to the pre-programmed schedule is straightforward. Simply press the “ON” button one more time. This action disengages the override mode‚ and the timer will revert to executing the programmed on and off times as originally set.
The display will reflect the current time and the next scheduled event‚ confirming the timer is back in automated mode. No settings are altered or erased during the override process; it’s a temporary suspension of the programmed schedule. Ensure the timer is correctly displaying the current time for accurate operation. If any discrepancies are observed‚ refer to the section on setting the current time for adjustments.
Troubleshooting Common Issues
If the Woods 50007 fails to operate‚ check power connections and the programmed schedule. Incorrect time or a non-executing program requires resetting.
Timer Not Turning On
If your Woods 50007 timer isn’t powering on‚ several factors could be at play. First‚ verify the timer is securely plugged into a functioning wall outlet; test the outlet with another device to confirm it’s providing power.
Next‚ ensure the device plugged into the timer is switched ON. The timer controls power to the device‚ but doesn’t power it on independently. Also‚ confirm the internal battery has received an initial 10-minute charge as outlined in the setup instructions.
A depleted battery can prevent operation‚ even when plugged in. Finally‚ double-check that no on/off programs are currently active that might be preventing power flow at the current time. Resetting the timer to factory defaults can sometimes resolve persistent issues.
Incorrect Time Display
An inaccurate time display on your Woods 50007 timer can disrupt programmed schedules. To correct this‚ you must re-enter time setting mode. Press and hold the “SET” button for approximately two seconds until the time display begins to flash.
Use the “Hour” and “Minute” buttons (often indicated by “+” and “-” symbols) to adjust the displayed time to the correct current time. Remember to pay attention to AM/PM if your timer utilizes a 12-hour clock format.
Press “SET” again to confirm each adjustment and exit time setting mode. If the issue persists‚ try briefly disconnecting the timer from the power outlet to reset it‚ then repeat the time-setting process.
Program Not Executing
If your Woods 50007 timer isn’t following the programmed on/off schedule‚ several factors could be at play. First‚ verify the timer isn’t in “Manual Override” mode – ensure the indicator isn’t lit‚ signifying manual control. If it is‚ press the override button to return to timed operation.
Double-check that the programmed on and off times are correctly set‚ paying close attention to AM/PM designations. Confirm the timer is securely plugged into a functioning outlet and that the connected device is also switched on.
A low battery can sometimes cause erratic behavior; consider replacing the battery. If problems continue‚ try resetting the timer by briefly unplugging it.
Safety Precautions
Always use the Woods 50007 timer indoors only‚ adhering to electrical safety guidelines. Do not exceed the maximum load capacity for safe operation.
Indoor Use Only
Crucially‚ the Woods 50007 digital timer is specifically designed and rated for indoor application only. Utilizing this device outdoors exposes it to elements like moisture‚ rain‚ and extreme temperatures‚ which can create a significant electrical hazard.
Outdoor exposure can compromise the timer’s internal components‚ leading to malfunction‚ short circuits‚ or even fire. Protecting the timer from the elements ensures its longevity and‚ more importantly‚ your safety.
Avoid using it in damp or wet locations‚ such as bathrooms or near water sources. Always ensure the outlet the timer is plugged into is dry and protected from potential water damage. Strictly adhering to indoor use guidelines will maintain the timer’s performance and prevent dangerous situations.
Electrical Safety Guidelines
Prioritize electrical safety when using the Woods 50007 timer. Always ensure the outlet is properly grounded and matches the timer’s voltage requirements. Never overload the timer; adhere strictly to the maximum load capacity specified in the manual to prevent overheating and potential fire hazards.
Avoid using the timer with damaged cords or plugs. Inspect them regularly for wear and tear. Disconnect the timer from the outlet before cleaning or performing any maintenance. Do not attempt to disassemble or repair the timer yourself; this could lead to electrical shock or damage the device.
Keep the timer away from flammable materials and ensure adequate ventilation around the device. If you notice any unusual smells or sounds‚ immediately unplug the timer and discontinue use.
Maximum Load Capacity
Understanding the Woods 50007’s maximum load capacity is crucial for safe and effective operation. This timer is generally rated for a maximum of 15 amps‚ or 1875 watts‚ at 125 volts. Exceeding this limit can cause overheating‚ damage the timer‚ and potentially create a fire hazard.
Before connecting any device‚ verify its wattage rating. If the device’s wattage exceeds the timer’s capacity‚ do not use it with the timer. Consider using a higher-capacity timer designed for heavier loads. Always check the device’s label or manual for its power consumption details.
Using appliances above the specified limit voids any warranty and poses a significant safety risk. Prioritize safety by staying within the recommended load capacity.
Additional Resources
For a complete Woods Timer 50007 manual download‚ and to explore frequently asked questions‚ visit online resources for detailed support and guidance.
Woods Timer 50007 Manual Download
Accessing the full Woods Timer 50007 manual is crucial for understanding all its features and functionalities. While a direct official download link isn’t prominently displayed on the Woods website‚ several resourceful online platforms archive and host this documentation.
Websites dedicated to appliance manuals and user guides frequently offer a downloadable PDF version of the Woods 50007 instruction manual. Searching for “Woods 50007 manual” on these sites will likely yield results.
Furthermore‚ retailers like Amazon‚ where the timer is sold‚ sometimes provide links to the manual within the product information section. Reviewing these resources will provide comprehensive details on setting the time‚ programming on/off schedules‚ override functions‚ and troubleshooting common issues. Always refer to the manual for the most accurate and up-to-date information.
Frequently Asked Questions (FAQ)
Q: How do I set the time on my Woods 50007 timer? A: Press and hold the “SET” button for approximately two seconds. Then‚ use the “Hour” (+) or (-) buttons to adjust the hour‚ and press “SET” again to confirm. Repeat this process for the minutes.
Q: Can I override the timer’s programmed schedule? A: Yes‚ simply press the “ON” button to manually activate the timer‚ overriding the programmed settings. Pressing the “OFF” button will manually deactivate it.
Q: What if my timer isn’t turning on? A: Ensure the timer is securely plugged into a working outlet. Also‚ verify the device plugged into the timer is switched on. A fresh battery charge may also be necessary.
Q: How do I program multiple on/off cycles? A: Refer to the full manual for detailed instructions on setting up multiple programs.
